Standard Features
- Certification: ANSI A156.2, Series 4000, Grade 2, 400,000 cycles, ANSI A117.1 accessibility (ADA)code, UL listed for 3 hour fire door.
- Chassis: Cylindrical, steel-coated w/zinc dichronate (corrosion resistance).
- Lever: Nonhanded.
- Latch: 1-1/8″ x 2-1/4″ square corner faceplate, 3/4″ housing, 1/2″ throw (stainless steel).
- Thru-bolts REMOVEABLE.
- Backset: 2-3/4″
- Strike: Square corner 1-1/4″ x 4-7/8″ ANSI ASA Strike.
- Door Range: 1-1/2″ to 2″.
- Door Preparation: 2-1/8″ diameter for bore, 1″ diameter latch bore.
Fits standard 161 door prep.
- Cylinder: Schlage C 6-pin (SCC) Keyway. 2 nickel silver keys per lock.
- Warranty: One year manufacturer’s limited warranty.
